GTV 2.0
- To create ergonomic workplaces
- Load range from 20 to 60 kg
- Very good hovering behavior
- Continiuous potential equalisation
- Load area can be accurately adapted by the user
- Freely positionable version
- Friction element to adjust the necessary effort
Included in delivery
- Height adjustment incl. fixing material. (assembly components for a connection to the machine and to the control enclosure are not included)
Product Information
| Technical Data | |||
| Material |
Connecting plate: S235 Components: EN 1706 AC-46000DF Cable channel cover sheet: EN 573-3 AW-5754 H22 |
||
| Colour |
Powder coating, Connecting plate: RAL 7016, Components: RAL 7035, Cable channel cover sheet: RAL 7035 |
||
| Load range |
20-60kg |
||
| Life time | 25.000 double strokes | ||
| Temperature range | up to approx. 45 °C | ||
| Product Range | |||
| Order-No. | Type | weight（g） | |
| 49.85 50 01 | GTV 2.0 Load range 1 hanging | 17000 | |
| 49.85 50 02 | GTV 2.0 Load range 2 hanging | 17000 | |
| 49.85 50 03 | GTV 2.0 Load range 3 hanging | 17000 | |
| 49.85 51 01 | GTV 2.0 Load range 1 upright | 17000 | |
| 49.85 51 02 | GTV 2.0 Load range 2 upright | 17000 | |
| 49.85 51 03 | GTV 2.0 Load range 3 upright | 17000 | |
| Load range | ||
| Load range1 | 20-32kg | |
| Load range2 | 32-44kg | |
| Load range3 | 44-60kg | |
