Technical Data
Material	Tube: stainless steel 1.4301 System components: Stainless steel 1.4305
Ingress protection	IP 65 to EN 60529
Surface	grinded, grain 240
Free cable passage	GTH 48: 41mm GTH 60: 53mm
Temperature range	-25°C to +60°C

Product Range
GTH 48	GTH 60
Order-No.	Order-No.	Type
57.01 73 00	57.02 73 00	Coupling
57.01 73 01	57.02 73 01	Coupling EMC
57.01 73 02	57.02 73 02	Coupling for external tube fitting
57.01 66 00	57.02 66 00	Top-mounted joint
57.01 66 01	57.02 66 01	Top-mounted joint EMC
57.01 66 02	57.02 66 02	Coupling for external tube fitting
57.01 74 00	57.02 74 00	Foot stand (hanging / standing)
57.01 74 01	57.02 74 01	Top-mounted foot stand
57.01 72 00	57.02 72 00	Foot stand with cable outlet (hanging / standing)
57.01 72 01	57.02 72 01	Foot stand with cable outlet (top-mounted)
57.01 76 00	57.02 76 00	Console adapter
57.01 79 00	57.02 79 00	Wall console
57.01 00 05	57.02 00 05	Tube I ( 500mm )
57.01 00 10	57.02 00 10	Tube I ( 1000 mm )
57.01 00 15	57.02 00 15	Tube I ( 1500 mm )
57.01 00 99	57.02 00 99	Tube I special length
57.01 02 02	57.02 02 02	Tube S ( 500mm )
57.01 02 10	57.02 02 10	Tube S ( 1000mm )
57.01 02 99	57.02 02 99	Tube S special length
57.01 01 05	57.02 01 05	Tube J ( 500 mm )
57.01 01 07	57.02 01 07	Tube J ( 740 mm )
57.01 01 10	57.02 01 10	Tube J (1000 mm )
57.01 01 99	57.02 01 99	Tube J special length
57.00 99 00	57.00 99 00	System mounting
