ROSE
Product center
GT 60/2,GT 80/2
- Robust industrial square suspension arm system for system components
- modular construction for individual components
- High loading capacity, large extention
Included in delivery
- Individual system components incl. assembly materials
Product Information
| Product Range | |||
| Material |
Connecting tube: square steel tube similar to DIN EN 10305-5 Wall thickness 5 mm Components: spheroidal graphite cast iron and/or cast aluminium |
||
| Ingress protection | IP 54 to EN 60529 | ||
| Seals | CR and/or NBR | ||
| Colour |
Powder coating, Tube: galvanized, Components: RAL 7043, traffic grey B, special colour on request |
||
| Free cable passage |
GT60/2 25cm²（40*40mm） GT80/2 49cm²（40*40mm） |
||
| Product Range | ||||
| GT 60/2 | ||||
| Order-No. | Type | |||
| 49.81 66 00 | Top mounted joint | |||
| 49.81 74 00 | Foot stand, cast steel | |||
| 49.81 70 00 | Flange coupling | |||
| 49.81 79 00 | Adapter flange for wall joint | |||
| 49.81 67 00 | Intermediate joint | |||
| 49.81 80 00 | Angle, cast steel | |||
| 49.81 75 00 | Angle coupling | |||
| 49.81 78 00 | Angle flange coupling | |||
| 49.81 73 00 | Coupling | |||
| 49.81 77 00 | Flange coupling | |||
| 49.81 62 00 | Console coupling DN | |||
| 49.81 76 00 | Console adapter 30° | |||
| 49.81 80 10 | Signal fitting | |||
| GT 60/2 | GT 80/2 | Connecting tube | ||
| Order-No. | Order-No. | |||
| 10.09 42 23 | 10.09 42 27 | Standard length 1m | ||
| 10.09 42 24 | 10.09 42 28 | Standard length 1m | ||
| 10.09 42 25 | 10.09 42 29 | Standard length 1m | ||
| 10.09 42 26 | 10.09 42 30 | Standard length 1m | ||
| 10.09 41 57 | 10.09 41 59 | Variable length (please specify) | ||
Belastungsdiagramm
