Technical data
Material	Coupling: DIN EN 1706 EN AC-AISi12(Fe) Connecting tube: DIN EN 573 EN AW-AlMgSi Angle cover: ABS
Ingress protection	IP 54 to EN 60529
Color	Couplings, connecting tube: light grey RAL7035 Cover plate black
Cable passage	Diameter 46

Product range
Order No.	Type	Weight(Kg)
GTC 6600	Top mounted joint	1.4
GTC 7000	Wall hinge	1.7
GTC 6200	Wall hinge(vertical)	1.6
GTC 7100	Angle	0.6
GTC 7200	Foot stand,fixed	0.6
GTC 7220	Turnable foot stand	0.8
GTC 7300	Coupling	1
GTC 7500	Angle coupling	1.1
GTC 7700	Flange coupling,turnable	1.3

Connecting tube
Order No		Weight(Kg)
GTC 1001	Standard length：0.5m	1.7
GTC 1002	Standard length:1m	3.4
GTC 1003	Standard length:2m	6.8
GTC 1099	Special length（According to 50 mm size, length ratio increases）

Belastungsdiagramm

Note: the vertical length of the profile is responsible for the load of the complete support arm system (lever arm!). Further information for this on request. The values in the load diagram are apply to an execution hanging or standing. The declarations of weight are a summary from installation weight, Commander and all components and tubes between Commander and angle.
