GT 48/2 - 美卡诺元器件（上海）有限公司

Technical Data
Material	Connecting tube: steel 48 x 4 mm DIN 2393-St. 37 Components: DIN EN 1706 EN AC-AlSi12 (Fe)
Ingress protection	IP 54 to EN 60529
Seals	CR and/or NBR
Colour	Powder coating, Tube: galvanized, Components: RAL 7043, traffic grey B, special colour on request
Free cable passage	Connecting tube: 40 mm diameter System components: 40 mm diameter

Product Range
Order-No.	Type	Weight(Kg)
49.49 66 00	Top mounted joint	2.0
49.49 72 00	Foot stand, fixed	1.0
49.49 68 00	Foot stand, turnable	1.8
49.49 70 00	Wall hinge W	3.0
49.49 62 00	Wall hinge S	2.7
49.49 71 00	Angle	1.2
49.49 73 00	Coupling	1.1
49.49 77 00	Flange coupling	1.1
49.49 77 02	Flange coupling Siemens-PRO	1.3
49.49 75 00	Flange coupling Siemens-PRO	1.3
49.49 78 00	Angle flange coupling	1.3
49.49 78 02	Angle flange coupling Siemens-PRO	1.5
49.49 76 00	Console flange 30°	0.4
49.49 79 00	Flange adapter	1.5
49.49 80 00	Adapter flange	0.8
49.49 90 01	Flat panel adapter	1.4
49.49 00 01	Adapter plate GT48/2-PRO	0.2

Connecting tube
Adapter flange		weight(Kg)
10.09 42 16	Standard length：0.5m	2.15
10.09 42 17	Standard length:1m	4.3
10.09 42 18	Standard length:2m	8.6
10.09 42 19	Standard length:3m	12.9
10.09 42 58	Variable length (please specify)

Belastungsdiagramm

Note: the vertical length of the profile is responsible for the load of the complete support arm system (lever arm!). Further information for this on request. The values in the load diagram are apply to an execution hanging or standing. The declarations of weight are a summary from installation weight, Commander and all components and tubes between Commander and angle.
