Product center
GTS
- Aluminium profile suspension system for light/medium loads up to 30 kg
- Product family GTN / GTS
- Combined with all Commander systems
- Adjustable version for individual loads
Included in delivery
- Individual system components incl. assembly materials
Product Information
| Technical Data | |
| Material |
Connecting tube: DIN EN 573 EN AW-AlMgSi Components: DIN EN 1706 EN AC-AlSi12 (Fe) |
| Ingress protection | IP 54 to EN 60529 |
| Seals | CR and/or PU foam |
| Colour | Powder coating, Tube, components: RAL 7035, light grey |
| Free cable passage |
Connecting tube: 53 x 19 mm System components: 53 x 19 mm |
| Belastungsdiagramm |  |
| Product Range | ||||
| Order-No. | Type |
|
||
| 49.44 66 00 | Attachment joint | |||
| 49.44 72 00 | Foot stand | |||
| 49.44 70 00 | Wall hinge W | |||
| 49.44 71 00 | Angle | |||
| 49.44 71 44 | Angle GTN II / GTS |
|
||
| 49.44 73 00 | Coupling | |||
| 49.44 77 00 | Flange coupling | |||
| 49.44 75 00 | Angle coupling | |||
| 49.44 90 01 | 平板转接件 | |||
| 49.44 72 21 | Turnable food stand | |||
| 49.44 80 00 | Inclining adapter | |||
| 49.44 73 02 | Coupling Siemens-PRO | |||
| 49.44 75 02 | Angle coupling Siemens-PRO | |||
| 49.44 00 01 | Adapter plate Siemens-PRO | |||
| Aluminium profile | Maximum reach 1.5m | |||
| Order-No. | Connecting tube | |||
| 49.44 10 01 | Standard length：0.5m | |||
| 49.44 10 02 | Standard length:1m | |||
| 49.44 10 03 | Standard length:2m | |||
| 49.44 99 99 | Variable length (please specify) | |||
| *No threaded holes | ||||
