Product center
Multitronic TS/TS-F
- Aluminium electronic enclosure for MCR technology
- Variable length version using profile technology
- Single or clam-shell enclosure construction with heat sink option
Included in delivery
- Enclosure with two aluminium lids, screwed.
Product Information
| Technical Data | |
| Material | DIN EN 573 EN AW-AIMgSi |
| Colour | Powder coating, RAL 9005, jet black |
| Ingress protection | IP 40 to EN 60529 |
| Temperature range | -40°C to +100°C |
| Product Range | |||
| Order-No. | Dimensions H x W x D (mm) | Type | |
| 77.01 11 00 | 46 x 105 x 72 | TS 111 | |
| 77.01 12 00 | 46 x 105 x 72 | TS 112 | |
| 77.01 21 00 | 76 x 105 x 61 | TS 121 | |
| 77.01 22 00 | 76 x 105 x 61 | TS 122 | |
| 77.01 41 00 | 105 x 105 x 57 | TS 141 | |
| 77.01 42 00 | 105 x 105 x 57 | TS 142 | |
| 77.02 21 00 | 76 x 105 x 51 | TS 221 | |
| 77.02 22 00 | 76 x 105 x 51 | TS 222 | |
| 77.02 31 00 | 76 x 105 x 64.5 | TS 231 | |
| 77.02 32 00 | 76 x 105 x 64.5 | TS 232 | |
| 77.03 31 00 | 76 x 105 x 78 | TS 331 | |
| 77.03 32 00 | 76 x 105 x 78 | TS 332 | |
| 77.04 41 00 | 105 x 185 x 45 | TS 441 | |
| 77.04 42 00 | 105 x 185 x 45 | TS 442 | |
| 77.04 61 00 | 105 x 185 x 66 | TS 461 | |
| 77.04 62 00 | 105 x 185 x 66 | TS 462 | |
| 77.06 62 00 | 105 x 185 x 87 | TS 662 | |
| 77.41 11 00 | 46 x 105 x 72 | TS 111-F | |
| 77.41 12 00 | 46 x 105 x 72 | TS 112-F | |
| 77.41 21 00 | 76 x 105 x 61 | TS 121-F | |
| 77.41 22 00 | 76 x 105 x 61 | TS 122-F | |
| 77.41 41 00 | 105 x 105 x 57 | TS 141-F | |
| 77.41 42 00 | 105 x 105 x 57 | TS 142-F | |
| 77.42 21 00 | 76 x 105 x 51 | TS 221-F | |
| 77.42 22 00 | 76 x 105 x 51 | TS 222-F | |
| 77.42 31 00 | 76 x 105 x 64.5 | TS 231-F | |
| 77.42 32 00 | 76 x 105 x 64.5 | TS 232-F | |
| 77.43 31 00 | 76 x 105 x 78 | TS 331-F | |
| 77.43 32 00 | 76 x 105 x 78 | TS 332-F | |
| 77.44 41 00 | 105 x 185 x 45 | TS 441-F | |
| 77.44 42 00 | 105 x 185 x 45 | TS 442-F | |
| 77.44 61 00 | 105 x 185 x 66 | TS 461-F | |
| 77.44 62 00 | 105 x 185 x 66 | TS 462-F | |
| 77.46 62 00 | 105 x 185 x 87 | TS 662-F |
