Product center
Profitronic I/F
- Aluminium electronic enclosures for MCR technology and automation engineering
- Variable length version using profile technology
- Enclosure system with different front lid and rear panel versions
- Integrated guide grooves for PCB’s
Included in delivery
- Enclosure with two sheet aluminium or cast lids, screwed; version with protective collar lid have self-adhesive anodized aluminium front panel is added separate
Product Information
| Technical Data | |
| Material | Aluminium DIN EN 573 EN AW-AlMgSi |
| Colour | Powder coating, Enclosure lid: RAL 7030, stone grey, Enclosure profile: RAL 7035, light grey |
| Ingress protection |
IP 65 or IP 40 to EN 60529 depending on lid versions |
| Temperature range | -40°C to +80°C |
| Other versions on request |
EMC |
| Product Range | |||
| Order-No. | Dimensions H x W x D (mm) | Type | |
| 07.05 20 12 | 104 x 129 x 84.5 | 07.05 | |
| 07.05 21 12 | 104 x 129 x 84.5 | 07.05 | |
| 07.05 22 12 | 112 x 147 x 91.5 | 07.05 | |
| 07.05 23 12 | 112 x 149 x 91.5 | 07.05 | |
| 07.05 24 12 | 112 x 181 x 91.5 | 07.05 | |
| 07.05 25 12 | 112 x 164 x 91.5 | 07.05 | |
| 07.05 26 12 | 112 x 166 x 91.5 | 07.06 | |
| 07.06 20 18 | 165 x 184 x 105 | 07.06 | |
| 07.06 21 18 | 165 x 184 x 105 | 07.06 | |
| 07.06 22 18 | 172 x 202 x 112 | 07.06 | |
| 07.06 23 18 | 172 x 204 x 112 | 07.06 | |
| 07.06 24 18 | 172 x 236 x 112 | 07.06 | |
| 07.06 25 18 | 172 x 219 x 112 | 07.06 | |
| 07.06 26 18 | 172 x 221 x 112 | 07.06 | |
| 07.06 27 18 | 173 x 204 x 113 | 07.06 | |
| 07.06 28 18 | 173 x 206 x 113 | 07.06 | |
| 07.06 29 18 | 173 x 225 x 113 | 07.06 | |
| 07.06 30 18 | 173 x 227 x 133 | 07.06 | |
| 07.07 20 18 | 196 x 184 x 166.5 | 07.07 | |
| 07.07 21 18 | 196 x 184 x 166.5 | 07.07 | |
| 07.07 22 18 | 203 x 202 x 166.5 | 07.07 | |
| 07.07 23 18 | 203 x 204 x 166.5 | 07.07 | |
| 07.07 24 18 | 203 x 236 x 166.5 | 07.07 | |
| 07.07 25 18 | 203 x 219 x 166.5 | 07.07 | |
| 07.07 26 18 | 203 x 221 x 166.5 | 07.07 | |
| 07.07 27 18 | 204 x 204 x 166.5 | 07.07 | |
| 07.07 28 18 | 204 x 206 x 166.5 | 07.07 | |
| 07.07 29 18 | 204 x 225 x 166.5 | 07.07 | |
| 07.07 30 18 | 204 x 227 x 166.5 | 07.07 |
