Technical Data | |
Material |
Aluminium DIN EN 573 EN AW-AlMgSi DIN EN 1706 EN AC-AlSi 12 (Fe) |
Colour | Powder coating, Enclosure profile: RAL 7035, light grey, Enclosure lid: RAL 7030, stone grey |
Ingress protection |
IP 65 to EN 60529 Outdoor application on request |
opening angle | Connection compartment and transparent cover: 110° |
Temperature range |
Lid seal: -40°C to +80°C |
Other versions on request |
EMC |
Product Range | |||
Order-No. | Dimensions H x W x D(mm) | Type | |
07.19 21 11 | 148 x 285 x 241 | PT 19U-01 | |
07.19 22 11 | 148 x 264 x 149 | PT 19U-02 | |
07.19 31 11 | 148 x 273 x 149 | PT 19U-03 | |
07.19 32 11 | 148 x 253 x 149 | PT 19U-04 | |
07.28 21 11 | 191 x 285 x 241 | PT 19U-05 | |
07.28 22 11 | 191 x 264 x 149 | PT 19U-06 | |
07.28 31 11 | 191 x 273 x 241 | PT 19U-07 | |
07.28 32 11 | 191 x 253 x 149 | PT 19U-08 | |
07.42 22 11 | 265 x 264 x 149 | PT 19U-10 | |
07.42 32 11 | 265 x 253 x 149 | PT 19U-12 |
