Characteristics | ||||
Colour | Black, similar to RAL 9005; special colours on request | |||
Protection Class | ABP, ABPH: up to IP 65/DIN EN 60529; ABPU: IP 40/DIN EN 60529 | |||
Enclosure Material |
Extruded profiles: Al Mg Si 0.5 powder-coated; diecast lid: GB Al Si 12, powder-coated; seal: TPE; for details see Technical Information |
Universal aluminium profile enclosure, IP 65
The flexible length and profile variantsclosed (ABP), horizontally-divided (ABPH),horizontally-divided with heat-sink (ABPHK) or open on one side (ABPU) offer theright enclosure for every application. |
The recessed profile sides are suitable forfitting membrane keypads. The sidesurfaces are ergonomically designed. 设计 |
Good EMC protection by means of contactsurfaces which contact the lid to theprofile. EMC seals are available if greaterprotection is required |
ABD – end cover with a recessed area forfitting front membranes or membranekeypads. |
ABM...AL – mounting lid with a recessedmounting area. An aluminium cap withseal can be snapped on to achieve IP 65protection |
ABM...SAL – Mounting lid with a hingedaluminium flap, IP 65 |
ABM...IR – mounting lid with a recessedmounting area. An infrared-permissiveplastic cap can be snapped on to achieveIP 65 protection.
|
DI... – a black seal is included with all lids.Coloured seals and an EMC or UL 94 V0seal are also available. |
Various optional accessory componentssuch as impact protection, wall brackets,tip-up and standard handles are available |
