Elegant design and flexible construction are the main features of this metal enclosure
- 3 heights
- Length and width are individually adjustable
- 36 standard dimensions ex warehouse
- Aluminium baseplates and top covers
- Good EMC characteristics as standard
- Higher shielding values possible with accessories
- Installation of 19" components possible
- For use as 19" chassis
- Comprehensive range of accessories
| Characteristics | ||||
| Colour | Graphite grey, similar to RAL 7024; special colours on request | |||
| Protection Class | IP 40/DIN EN 60529; with ventilation (ADL) IP 20/DIN EN 60529 | |||
| Enclosure Material | Profiles: Al Mg Si 0.5; diecast corners: zinc alloy Z410; seal: TPE. For details see Technical Information. | |||
Elegant design and flexible construction are the mainfeatures of this metal enclosure
|
IntertegoIntertego is suitable for use as 19"enclosures. For EMC accessories, see theend of the chapter. |
The enclosure’s EMC properties can beoptimised by the use of special EMCcomponents. |
Wall angles or fittings make possible wallmounting in two positions. |
|
The lateral system groove is used, forexample, to hold decor strips for acolourful design. |
A tower foot is available as an accessoryfor vertical use of the enclosure |
Tip-up feet are available as accessories andensure that the enclosure stands securelyon a desktop. |
|
Optional handle shells can be fitted in theside profiles to make transporting theenclosure easy. |
|
|
