Clear lines and natural-coloured anodised aluminium characterise this profile enclosure
- 3 profile variants
- 4 profile cross-sections
- 3 standard lengths ex warehouse
- Special lengths available at short notice
- End covers made of ABS, similar to RAL 9005
- End covers also available with moulded-on wall fitting
- Console type on request
| Characteristics | ||||
| Colour | Profile natural-coloured anodised aluminium; Black plastic lid, similar to RAL 9005 Dust grey, similar to RAL 7037; special colours on request |
|||
| Protection Class | IP 40/DIN EN 60529; ELP with optional seal, upgradable to IP 54/DIN EN 60529; ELPH with IP 54/DIN EN 60529 on request | |||
| Enclosure Material | Extruded profiles: Al Mg Si 0.5 anodised; plastic lid: ABS; for details see Technical Information | |||
Clear lines and natural-coloured anodised aluminiumcharacterise this profile enclosure
|
The variable lengths and profile variantsclosed (ELP), horizontally divided (ELPH) oropen on one side (ELPU) provide the rightenclosure for every application. |
Recessed profile top side and profilebottom side for fitting membrane keypadsup to 2 mm.
|
By using seal EL...DI, the protection classof profile variant ELP can be increasedfrom IP 40 to IP 54.
|
|
ELP...D – End cover without wall fitting |
ELP...DW – End cover with integrated wallfitting |
All end covers have a 1.5 mm deeprecessed area for fitting membranekeypads. |
|
Screw-on bosses in the lid which arematched to the height of short-stroke keysfor fitting PCBs parallel to the front surface(not with ELP 620 |
|
|
