ROSE
Product center
Aluform
- Aluminium diecast enclosure for MCR and automation technology
- Prepared for acceptance for front membranes and keypads
- Rectangular dome sequence in lid and base
Included in delivery
- Aluminium diecast enclosure consisting of lid, seal incl. captive +/- stainless steel screws, base with 4 earthing screws
Product Information
| Technical Data | |
| Material | DIN EN 1706 EN AC-AlSi 12 (Fe) |
| Ingress protection |
IP 66 to EN 60529，higher protection on request |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Temperature range |
PU (polyurethane) seal (std.): -40°C to +90°C |
| Colour | Powder coating, RAL 7038, agate grey, special colour on request |
| Other versions on request | EMC, SBG, SBGL, SWB, Silicone lid seal |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 04.08 08 08 | 80 X 80 X 81 | ALF 04010 | ||
| 04.08 12 05 | 80 X 120 X 50 | ALF 04015 | ||
| 04.08 12 08 | 80 X 120 X 81 | ALF 04020 | ||
| 04.10 10 06 | 100 X 100 X 61 | ALF 04025 | ||
| 04.10 16 06 | 100 X 160 X 61 | ALF 04030 | ||
| 04.10 20 06 | 100 X 200 X 61 | ALF 04035 | ||
| 04.12 12 08 | 120 X 120 X 81 | ALF 04040 | ||
| 04.12 16 08 | 120 X 160 X 81 | ALF 04045 | ||
| 04.14 14 07 | 140 X 140 X 71 | ALF 04050 | ||
| 04.14 18 07 | 140 X 180 X 71 | ALF 04055 | ||
| 04.14 22 07 | 140 X 220 X 72 | ALF 04060 | ||
| 04.15 18 08 | 150 X 180 X 81 | ALF 04065 | ||
| 04.16 16 08 | 160 X 160 X 81 | ALF 04070 | ||
| 04.16 24 08 | 160 X 240 X 81 | ALF 04075 | ||
| 04.20 20 07 | 200 X 200 X 72 | ALF 04080 | ||
| 04.20 28 07 | 200 X 280 X 72 | ALF 04085 | ||
| 04.28 28 11 | 280 X 280 X 111 | ALF 04090 |
