Beluga
- Polyamide hand held enclosure for MCR- and automation engineering
- Version with or without display opening
- Prepared for acceptance of keypads/silicone switch mats
- Optional EMC version with internal coating and EMC-seal
Included in delivery
- Double-skinned enclosure with top and base unit, each with fixing domes, fastening and enclosure screws.
Product Information
| Technical Data | |
| Material | Polyamide |
| Colour | RAL 7021, black grey |
| Ingress protection | IP 65 to EN 60529 |
| Flammability | UL 94 V-2 |
| Surface resistance | 1012 Ohm to IEC 60093 |
| Temperature range | -40°C to +60°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 27.02 02 00 | 106/75 x 187 x 50 | Beluga 180 O | ||
| 27.02 02 01 | 106/75 x 187 x 50 | Beluga 180 G | ||
| 27.02 04 00 | 106/75 x 187 x 50 | Beluga 220 O | ||
| 27.02 04 00 | 116/85 x 220 x 51 | Beluga 220 G | ||
| 27.02 05 01 | 380 x 117 x 68 | Beluga 380 |
