ROSE
Product center
Pilot10/20/30
- Hand held enclosure for MCR- and automation engineering
- Robust design (Polyamide or polyester)
- Version with handle and integrated cable entry (Pilot 10, 20 standard)
Included in delivery
-
Pilot 10/20: enclosure with handle, including cable gland M 20 x 1,5, front plate with fastening screw and wall holder
Pilot 30: two-part Polyester enclosure with self-adhesive aluminium front plate, enclosure screws and wall holder
Product Information
| Technical Data | |
| Material |
Pilot 10 and Pilot 20: polyamide Pilot 30: polyester |
| Colour | RAL 1003, signal yellow, Pilot 30: RAL 1021, rape yellow |
| Ingress protection |
Pilot 10 and Pilot 20: IP 65 to EN 60529 Pilot 30: IP 66 to EN 60529 |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Flammability |
Pilot 10 and Pilot 20: UL 94 HB Pilot 30: self-estinguishing UL 94 V-0 |
| Temperature range | -40°C to +60°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 29.30 01 00 | 115/75 x 93 x 200 | Pilot 20 | ||
| 29.40 02 00 | 70/75 x 93 x 190 | Pilot 10 | ||
| 29.50 01 00 | 164/75 x 116 x 295 | Pilot 30 |
