Product center
Limanda
- Polyamide hand held enclosure for MCR, automation engineering and data acquisition
- For installations and command devices mobile and stationary applicable
- Variable mounting depths
Included in delivery
-
Clam sheel enclosure with top and base, each with fixing domes incl. seals and border profile,
3 cover flaps for interface garages, screws and fixing materials for front panel mounting.
Product Information
| Technical Data | |
| Material |
Enclosure: Polyamide border profile: NBR, black |
| Colour | RAL 7021, black grey |
| Ingress protection | IP 65 to EN 60529 |
| Flammability | UL 94 V-2 |
| Surface resistance | 1012 Ohm to IEC 60093 |
| Temperature range | -20°C to +60°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 27.03 02 00 | 270 x 248 x 64 | Limanda II | ||
| 27.03 02 01 | 270 x 248 x 64 | Limanda II EMC | ||
| 27.03 03 00 | 311 x 281 x 72 | Limanda I | ||
| 27.03 03 01 | 311 x 281 x 72 | Limanda I EMC | ||
| 27.03 03 17 | 311 x 281 x 97 | Limanda I for OP17 |
For More Product Details
Please Scan The QR Code
Please Scan The QR Code
