Pilot 250
- Polyamide hand held enclosure for MCR- and automation engineering
- Large fitting space
- Version with closed or front frame lid
- Rear battery compartment
- Optional EMC version with internal coating and EMC seal
Included in delivery
- Double-skinned enclosure with top and base unit, each with fixing domes, battery compartment lid, fastening and enclosure screws
Product Information
| Technical Data | |
| Material | Polyamide |
| Colour | Base and Lid: RAL 7021, black grey, rear cover: RAL 5003, sapphire blue |
| Ingress protection | IP 65 to EN 60529 |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Flammability | UL 94 HB |
| Temperature range | -40°C to +60°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 29.25 00 01 | 140/120 x 280 x 86 | Pilot 250/1 | ||
| 29.25 00 02 | 140/120 x 280 x 86 | Pilot 250/2 |
