Aluminum flange enclosure
- Robust aluminum enclosure, with 4,6 or 8 flange openings
- Can be mounted with DIN rails.
Included in delivery
-
• Aluminum enclosure, lid, seal, screws and 2 or 4 earth screws.
-
• Flange plates are not included, pls order separately.
Product Information
| Technical data | |
| Material | DIN EN 1706 EN AC-AISi 12 ( Fe) |
| Paint | powder coating |
| Color | RAL 7001, silver grey, special colors on request |
| ngress protection | IP 65 to EN 60529 |
| Impact resistance | 7Joule to EN 60079-0 |
| Temperature range |
PU (polyurethane) seal(std.): - 40°C to +90°C CR (chloroprene) seal: -40°C to +100°C VMQ (silicone) seal(optional): -60°C to +130°C |
| Product range | ||||
| Order No. | Dimensions(mm) | Number of flange openings | ||
| W X L X H | ||||
| 11.23 20 11 | 230 X 200 X 111 | 4 | ||
| 11.23 28 11 | 230 X 280 X 111 | 4 | ||
| 11.23 40 11 | 230 X 400 X 111 | 6 | ||
| 11.23 60 11 | 230 X 600 X 111 | 8 |
| Accessories | ||||||||
| Order No. | DIN rails | Earth rails | External mounting brackets | Corrosion resistance | Lid screw | Silicone seal max. temperature +130°C | Sealing steel screws for lid | |
| TS | 35 | (number of clamps) | ¹) | ¹) | ||||
| 11.23 20 11 | • | 10 | • | • | • | • | • | |
| 11.23 28 11 | • | 16 | • | • | • | • | • | |
| 11.23 40 11 | • | 25 | • | • | • | • | • | |
| 11.23 60 11 | • | 40 | • | • | • | • | • | |
| ¹)Stainless steel | ||||||||
| Accessories | |
| Blind flange | 10.00 60 01 |
| Flange plate for connector HAN 6B | 10.00 60 06 |
| Flange plate for connector HAN 16B | 10.00 60 11 |
| Flange plate for connector HAN 24B | 10.00 60 24 |
