ROSE
Product center
Polyester cabinets
- Enclosure system with hinged lid for MCR technology
- Standard version or with window panel or transparent door (ABS)
Included in delivery
-
Enclosure consisting of base and door; please order door lock separately, press-in inserts in base for internal and external mounting
Product Information
| Technical Data | |
| Material | glass fibre reinforced thermoset polyester |
| Colour | Polyester: RAL 7032, pebble grey, special colour on request |
| Ingress protection | IP 65 to EN 60529 |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Disruptive strength | Polyester: 26 KV/mm, IEC 60243-1 |
| Insulation | fully insulated VDE 0100 |
| Flammability | Polyester: self-extinguishing, UL 94 V-0 |
| Surface resistance | Polyester: 4x1015 Ohm, IEC 60093 |
| Toxicity | halogen free |
| Temperature range |
-55°C to +90°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 21.20 25 00 | 200 X 250 X 150 | PKS 1 | ||
| 21.25 30 00 | 250 X 300 X 170 | PKS 2 | ||
| 22.20 25 00 | 200 X 250 X 150 | PKST 1 | ||
| 22.25 30 00 | 250 X 300 X 170 | PKST 2 |
