ROSE
Product center
CombiBox
- Polyester GRP enclosure systems of polyester resin for industrial application
- Two level fitting possibility
- Combination of several enclosures by connecting flange
Included in delivery
- Plastic enclosure consisting of lid ans base with screws, individual system and height adjustment of mounting frame and mounting plate by 4 fixing elements
Product Information
| Technical Data | |
| Material | glass fibre reinforced thermoset polyester |
| Colour | RAL 7000, squirrel grey, special colour on request |
| ngress protection | IP 66 to EN 60529 |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Disruptive strength | 18 KV/mm, IEC 60243-1 |
| Surface resistance | >1012 Ohm to IEC 60093 |
| Insulation | fully insulated VDE 0100 |
| Flammability | self-extinguishing, UL 94 V-0 |
| Toxicity | halogen free |
| Temperature range |
PU (polyurethane) seal (std.): -40°C to +90°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 02.01 22 15 | 177 x 177 x 145 | CombiBox 1 | ||
| 02.01 24 15 | 360 x 177 x 145 | CombiBox 2 | ||
| 02.01 44 15 | 360 x 360 x 145 | CombiBox 3 | ||
| 02.02 22 15 | 177 x 177 x 145 | CombiBox 1, EMC | ||
| 02.02 24 15 | 360 x 177 x 145 | CombiBox 2, EMC | ||
| 02.02 44 15 | 360 x 360 x 145 | CombiBox 3, EMC | ||
| Accessories | |
| 02.01 99 01 | Flange |
| 02.01 99 02 | Mounting frame177 x 177 mm CombiBox 1 |
| 02.01 99 03 | Mounting frame177 x 360 mm CombiBox 2 |
| 02.01 99 04 | Mounting frame360 x 360 mm CombiBox 3 |
| 02.01 99 05 | Fixing for mounting frame |
| 02.01 99 06 | Safety strip for lid |
| 02.01 99 07 | Nuts |
| 02.01 99 10 | Mounting plate CombiBox1 |
| 02.01 99 11 | Mounting plate CombiBox2 |
| 02.01 99 12 | Mounting plate CombiBox3 |
| 10.06 14 85 | DIN rail;TS 35/7.5 160 mm |
| 10.06 14 86 | DIN rail;TS 35/7.5110 mm |
| 10.06 14 87 | DIN rail TS 35/7.5 145 mm |
| 10.06 14 88 | DIN rail;TS 35/7.5 293 mm |
| 10.06 14 94 | Support plate CombiBox 110 |
| 10.06 14 95 | Support plate CombiBox360 |
| 10.06 14 96 | Support plate CombiBox长360 |
