10 sizes
Modern design, corresponding to the Bocube plastic enclosure
All enclosure components made of metal
Many versions are listed under UL file no. 196 706
Captive lid with smooth surface or recessed membrane keypad area
Hinge integrated in the enclosure design
BA-S variant with screwed-on cover (both sides) and recessed area for membrane keypads
No visible enclosure screws
Prepared for cost-efficient integration of pressure compensation elements

Product Information

Characteristics
Colour	Graphite grey, similar to RAL 7024; light grey, similar to RAL 7035; special colours on request
Protection Class	IP 66 / IP 68 (1,2 m - 2 h) / IP 69 DIN EN 60529 Versions with silicone seal / EMC screening: IP 66 Impact resistance IK 08 (max. IP 66 / IP 68) or IK 07 (IP 69) acc. to IEC 62262
Enclosure Material	Enclosure: GD Al Si 12, seal PU foamed; Hinges / covers: Al Mg Si 0.5 powder-coated / natural-coloured anodised Materials acc. to set of requirements R1 or R7 acc. to DIN EN 45545-2 of hazard level HL3

A new design and innovative features protect sensitivecomponents even in challenging environments

With its modern design, Bocube Alu setsnew design trends in the diecast enclosuresector.

The hinge ensures that the lid is captive.Depending on the mounting, it can beopened to the left or right, as required

The enclosure lids are available optionallywith (2 mm) or without a recessed surfacefor fitting HMI solutions.

The enclosure screws are concealed underdesign covers and are captive, like the lidscrews.

A seawater-resistant version (SWB) or aspecial EMC version is available onrequest. Additional information can befound in the “Technical Information”chapter

The base has a moulded-on insertionopening for a pressure compensationmembrane which can be factory-activated.

We supply coloured hinges on request;wall brackets are available as an option

All enclosure components are metal andcaptive-connected with the enclosure

The BA-S variant with a screwed-on cover(both sides) is especially suitable forapplications with e.g. a high vibrationload.

For More Product Details
Please Scan The QR Code

Back

Bocube Alu

发布时间：2020-11-26

阅读量：5206次

Characteristics
Colour	Graphite grey, similar to RAL 7024; light grey, similar to RAL 7035; special colours on request
Protection Class	IP 66 / IP 68 (1,2 m - 2 h) / IP 69 DIN EN 60529 Versions with silicone seal / EMC screening: IP 66 Impact resistance IK 08 (max. IP 66 / IP 68) or IK 07 (IP 69) acc. to IEC 62262
Enclosure Material	Enclosure: GD Al Si 12, seal PU foamed; Hinges / covers: Al Mg Si 0.5 powder-coated / natural-coloured anodised Materials acc. to set of requirements R1 or R7 acc. to DIN EN 45545-2 of hazard level HL3
