Bocube - 美卡诺元器件（上海）有限公司

Patented, innovative, hinged quick-release catch technology without screws: open with a screwdriver, close by hand
More than 25 sizes and 150 standard combination options
2 material types: ABS or PC UL 94 V0, flame-resistant and self-extinguishing
Captive lid with membrane keypad area, available in 2 variants: grey or crystal-clear
Elegant design, hinged quick-release catches available in different colours
Excellent recyclability because of mono-material plastics without injection-moulded metal parts

Product Information

Characteristics
Colour	Graphite grey, similar to RAL 7024; light grey, similar to RAL 7035; special colours on request
Protection Class	IP 66/IP 67 DIN EN 60529
Enclosure Material	PC V-0 material is flame-resistant, self-extinguishing and suitable for outdoor use (f1 listing acc. to UL 746C),

Unique, innovative, versatile enclosure made of ABS orpolycarbonate UL 94 V0

Bocube consists of few parts, so it caneasily be mounted by hand. Open it bymeans of a screwdriver (size 3).

Wall brackets can be used for all Bocubesizes and are screwed into the drillingholes on the back of the enclosure base.

As an alternative to the hinged catch, theenclosures can be screwed. The hingedcatch conceals the screws

Coloured hinges (tool-operated or hand-operated, as required). Transparent hingesavailable on request.

Rectangular front panels or PCBs can bemounted in the base (by using distancebolts) and in the lid.

PC UL 94 V0 material is suitable foroutdoor use (f1 listing acc. to to UL 746Cand corresponds to requirements set R 22acc. to DIN EN 45545-2 of hazard levelHL3
