Euromas-Aluminium / F05 - 美卡诺元器件（上海）有限公司

43 sizes
Listing under UL file no. E 196 706
The materials correspond to requirements set R1 or R7 acc. to DIN EN 45545-2 of hazard level HL3
Versions with silicone lid seal with higher temperature resistance (approx. 200°C)
Types with crystal-clear lid on request
EMC set on request for increasing electromagnetic shielding levels
Types with F05 insertion opening

Product Information

Characteristics
Colour	Silver grey, similar to RAL 7001; special colours on request.
Protection Class	IP 66/DIN EN 60529; higher protection class on request. Impact protection IK 09 acc. IEC 62262 (A 100 IK 08)
Enclosure Material	G Al Si 12, PU foamed seal For details see Technical Information

Robust aluminium enclosure with protection class IP 66

Some enclosures are also available onrequest with a crystal-clear lid.

A hinge can be fitted to the enclosure foreasy opening.

Circuit boards can be fitted in the base bymeans of screw domes

Alternative to the foamed seal: Versionwith silicone seal for higher temperatureresistance available on request.

A special EMC version is available onrequest.An SWB / SBGL (seawater-resistant)version for critical outdoor areas isavailable on request. Additionalinformation can be found in the “TechnicalInformation” chapter

Special versions with an aluminium orVestamid F05 insertion opening.

The Vestamid enclosures contain acentering ring (V...-ZR) and an insertionopening for PST cable glands (V...-PST).Some variants are also equipped with asight glass
