Characteristics | ||||
Colour | Graphite grey, similar to RAL 7024; light grey, similar to RAL 7035; special colours on request | |||
Protection Class | Up to IP 66 / IP 68 (1,2m - 2 h) DIN EN 60529 , depending on the model | |||
Enclosure Material | ABS, PC; seal: CR; UL 94 V0 types on request; CR or PU seal, foamed for details see Technical Information. |
Modular enclosure system which adapts perfectly toalmost every requirement
FO-K: The FO-K frame is used for edgecovering of a front panel (FP...K) and aterminal compartment. The integratedterminal compartment lid has a 1.5 mmrecessed area for the fitting of membranekeypads. The frame is pushed onto thebase, pressed tight in 2 places, andscrewed to the terminal compartment. Inconnection with base and front panel:protection class IP 40.
|
FP: Front panel, aluminium or plastic. TheFP...K version must be used for enclosureswith a terminal compartment, and theFP...BK version for enclosures with twoterminal compartments.
|
KRD: By using partitions and front panels,a terminal compartment can be separatedand closed on the front with the terminalcompartment lid. The terminalcompartment can be positioned asrequired on the locking or hinged side, oron both sides at the same time. Theterminal compartment lid is available inlight or graphite grey and has a recessedarea for the mounting of membranekeypads and membranes.
|
Laminated paper panel for dividing aterminal compartment. The partition isinserted and fixed using TP-F or frontpanel.
|
TP-F: Laminated paper partition for sealingoff the electronics compartment if amembrane lid is required in connectionwith a terminal compartment.
|
WB: The wall-mounting fastening bracketis made of powder-coated sheet steel. It isscrewed on the rear to the base. Easy wallfitting is guaranteed. As an alternative,with the help of this bracket the Bocardcan also be used as a console enclosure. |
BCD...HS2: The swivelling handle (fixedlock-in position every 15°) permits use asboth a carrying and set-up bow for desktopapplication. Anti-slip elements are fitted tothe side sections of the handle, ensuringnon-slip properties and stability. |
BCD...UWB: With the swivelling wallfitting, an enclosure with a flat base can bemounted on a wall in its optimal position
|
Bocard overview:
|
