Beluga Ex
- Hand held enclosures as empty enclosures for Ex-applications
- 3 enclosure sizes
- Optional version with display openings
Included in delivery
- Enclosure system consisting of top and base with seal.
- O version = open: with display screen and mounting material for window
Product Information
| Technical Data | |
| Explosion protection |
II 2G Ex e IIC Gb |
| Material | Polyamide 12 |
| Certificates |
IECEx PTB 09.0019U PTB 02 ATEX 1076U |
| Colour | RAL 9005, jet black |
| Ingress protection | IP 65 to EN 60529 |
| Impact resistance |
7 Joule to EN 60079-0 |
| Flammability | UL 94 HB |
| Surface resistance | <109 Ohm to IEC 60093 |
| Temperature range | -20°C bis +60°C |
| Other versions on request | EMC |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | Weight（g） | |
| 28.02 02 00 | 106/75 x 187 x 50 | Beluga 180 O ExB | 160 | |
| 28.02 02 01 | 106/75 x 187 x 50 | Beluga 180 G ExB | 170 | |
| 28.02 04 00 | 116/85 x 220 x 51 | Beluga 220 O ExB | 200 | |
| 28.02 04 01 | 116/85 x 220 x 51 | Beluga 220 G ExB | 210 | |
| 28.02 05 01 | 380 x 117 x 68 | Beluga 380 ExB | 520 |
