Product center
Fire protection enclosures E30
- Fire protection enclosure from special halogen free polyester material
- Enclosure system with general certification to DIN 4102 part 12
- Individual modification with special approval ceramic terminal blocks and cable glandsn
Included in delivery
- Enclosure system with DIN rail and external brackets. Optinal with maching and for the enclosure system with approved terminals and cable glands.
Product Information
| Technical Data | |
| Material | glass fibre reinforced, thermoset special polyester |
| Colour | RAL 2004, orange |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance | 7 Joule in reference to EN 60079-0 |
| Toxicity | halogen free |
| Seals | CR round seal |
| Temperature range | -40°C to +90°C |
| Product Range | ||||
| Order-No. | Dimensions WxHxD（mm） | Type | ||
| E30.12 12 09 | 120 x 120 x 90 | E3001 | ||
| E30.12 22 09 | 120 x 220 x 90 | E3002 | ||
| E30.16 16 09 | 160 x 160 x 90 | E3003 | ||
| E30.16 26 09 | 160 x 260 x 90 | E3004 | ||
| E30.25 26 12 | 250 x 260 x 120 | E3005 |
