Ex control enclosure-CS box
- Polyamide enclosure with individual fitting with control switches in 22.5 mm (mounted on lid or base) and indicator lights.
- With opening 22.5mm or without opening
- Cable glands M20/M25
Included in delivery
- Enclosure (lid and base) with screws and M20, M25 holes for cables
- Can be fitted with DIN rail TS 35/37,5mm and connecting plates
Product Information
| Technical data | ||
|
Ex mark Ex II 2G Ex II 2D |
Ex e IIC T6 Gb（increased safety） Ex ia IIC T6 Gb （intrinsic safety) Ex e [ia] IIC T6 （mixed type）Temperature range T5 or T4 on request |
|
| Certification |
IECEx PTB 09.0020U，PTB 02 ATEX 076U， IECEx PTB 09.0021，PTB 08 ATEX 1109 |
|
| /Material | Polyamide 12 | |
| Ingress protection | IP 66 to EN 60529 | |
| Color | RAL 9005，dark black | |
| Impact resistance | 7 Joule to EN 60079-0 | |
| Surface resistance | <109Ohm，IEC 60093 | |
| Temperature range | -20℃ to +60℃ | |
| Product range | ||||
| Ex empty enclosure | Ex-I junction box | Exe control station | Type | Dimension(mm) |
| Order No. | Order No. | Order No. | H x W x D | |
| 28.10 01 00 | 58.10 01 00 | 68.10 01 00 | Ex-CS Box 110-0 | 110x110x85 |
| 28.10 01 01 | 58.10 01 01 | 68.10 01 01 | Ex-CS Box 110-1 | 110x110x85 |
| 28.10 02 00 | 58.10 02 00 | 68.10 02 00 | Ex-CS Box 160-0 | 110x160x85 |
| 28.10 02 02 | 58.10 02 02 | 68.10 02 02 | Ex-CS Box 160-2 | 110x160x85 |
| 28.10 02 03 | 58.10 02 03 | 68.10 02 03 | Ex-CS Box 160-3 | 110x160x85 |
| 28.10 03 00 | 58.10 03 00 | 68.10 03 00 | Ex-CS Box 230-0 | 110x230x85 |
| 28.10 03 04 | 58.10 03 04 | 68.10 03 04 | Ex-CS Box 230-4 | 110x230x85 |
| 28.10 03 05 | 58.10 03 05 | 68.10 03 05 | Ex-CS Box 230-5 | 110x230x85 |
| Accessories | ||||
| 31.10 99 01 | CS Box 110 Remote technology for connecting plates/ Technor | |||
| 31.10 99 02 | CS Box 160 Remote technology for connecting plates/ Technor | |||
| 31.10 99 03 | CS Box 230 Remote technology for connecting plates/ Technor | |||
| 31.10 99 04 | Lid safety seal ( set = 2 pcs) | |||
| 31.10 99 05 | Insulated plugs | |||
| 10.06 14 91 | DIN railsTS35 /7, 5CS Box 110 | |||
| 10.06 14 92 | DIN railsTS35 /7, 5CS Box 160 | |||
| 10.06 14 93 | DIN railsTS35 /7, 5CS Box 230 |
