Ex d IIB+H2 Enclosure Series EJB
- Flameproof aluminium or stainless steel enclosure system suitable for assembly of terminals, switches and components
- Window optional
- External flameproof joint
- For gas group IIB + H2
Included in delivery
- Enclosure system consisting of a lower part and cover incl. hinge, mounting plate, inner and outer earth as well as an O-ring seal (optional)
Product Information
| Technical Data | |
| Certificates |
ITS 15 ATEX 18302X IECEx ITS 15.0041X |
| Explosion protection |
II 2 G Ex db IIB + H2 T6/T5 Gb |
| Material |
ALUMINIUM |
| Colour | Aluminium: RAL 7035, light grey, Stainless steel: unpainted, painting on request |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance |
7 Joule to EN 60079-0 |
| Temperature range |
-20°C to +75°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 40.10 30 10 | 220 x 170 x 152 | EJB 01 AL | ||
| 40.10 30 20 | 270 x 220 x 158 | EJB 02 AL | ||
| 40.10 30 30 | 320 x 270 x 166 | EJB 03 AL | ||
| 40.10 30 60 | 490 x 440 x 250 | EJB 06 AL | ||
| 40.10 30 90 | 780 x 560 x 440 | EJB 09 AL | ||
| 40.10 31 00 | 980 x 680 x 487 | EJB 10 AL | ||
| 40.20 30 10 | 220 x 170 x 152 | EJB 01 SS | ||
| 40.20 30 20 | 270 x 220 x 158 | EJB 02 SS | ||
| 40.20 30 30 | 320 x 270 x 166 | EJB 03 SS |
