Ex d IIB+H2 Enclosure Series IJB
- Flameproof aluminium enclosure system suitable for assembly of terminals, switches and components
- Combination of several enclosures possible due to internal flameproof joint
- Window optional
- For gas group IIB + H2
Included in delivery
- Enclosure system consisting of a lower part and cover incl. mounting plate, inner and outer earth as well as an O-ring seal
Product Information
| Technical Data | |
| Certificates |
DEK 18 ATEX 0112 U IECEx DEK 18.0068U DEK 18 ATEX 0117 X IECEx DEK 18.0073X |
| Explosion protection |
II 2 G Ex db IIB + H2 T6/T5/T4 Gb |
| Material | ALUMINIUM |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance |
7 Joule to EN 60079-0 |
| Temperature range |
-20°C to +75°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 40.10 40 10 | 320 x 220 x 223 | IJB 01 AL | ||
| 40.10 40 20 | 370 x 270 x 225 | IJB 02 AL | ||
| 40.10 40 30 | 420 x 320 x 247 | IJB 03 AL | ||
| 40.10 40 40 | 470 x 370 x 249 | IJB 04 AL | ||
| 40.10 40 50 | 530 x 430 x 283 | IJB 05 AL | ||
| 40.10 40 60 | 630 x 530 x 288 | IJB 06 AL |
