Ex d IIC Enclosure Series GUB
- Flameproof enclosure system suitable for assembly of terminals, switches and components
- For gas group IIC
Included in delivery
- Enclosure system consisting of a lower part and cover incl. mounting plate, inner and outer earth as well as an O-ring seal
Product Information
| Technical Data | |
| Explosion protection |
II 2 G Ex db IIC T6/T5/T4 Gb |
| Material |
ALUMINIUM |
| Certificates |
DEK 18 ATEX 0115 U IECEx DEK 18.0071U DEK 18 ATEX 0120 X IECEx DEK 18.0076X |
| Colour | RAL 7035, light grey |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance |
7 Joule to EN 60079-0 |
| Temperature range |
-20°C to +75°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 40.10 20 10 | 220 x 220 x 182 | GUB 01 AL | ||
| 40.10 20 20 | 270 x 270 x 182 | GUB 02 AL | ||
| 40.10 20 30 | 320 x 320 x 211 | GUB 03 AL | ||
| 40.10 20 40 | 370 x 370 x 217 | GUB 04 AL | ||
| 40.10 20 50 | 420 x 420 x 239 | GUB 05 AL | ||
| 40.10 20 60 | 470 x 470 x 247 | GUB 06 AL |
