Ex d IIC Enclosure Series TBE
- Flameproof aluminium or stainless steel enclosure system suitable for assembly of terminals and industrial type components
- Available in aluminium or stainless steel
- For gas group IIC
Included in delivery
- Enclosure system consisting of a lower part and cover incl. mounting plate, inner and outer earth as well as an O-ring seal
Product Information
| Technical Data | |
| Explosion protection |
II 2 G Ex db IIC T6/T5/T4 Gb |
| Material |
ALUMINIUM |
| Certificates |
DEK 18 ATEX 0114 U IECEx DEK 18.0070U DEK 18 ATEX 0119 X IECEx DEK 18.0075X |
| Colour | Aluminium: RAL 7035, light grey, Stainless steel: unpainted, painting on request |
| Ingress protection | IP 66 to EN 60529 |
| Surface | Powder coating |
| Impact resistance |
7 Joule to EN 60079-0 |
| Temperature range |
-60°C to +75°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 40.10 10 10 | 116 x 116 x 98 | TBE 100T AL | ||
| 40.10 10 13 | 148 x 148 x 107 | TBE 130T AL | ||
| 40.10 10 16 | 180 x 180 x 116 | TBE 160T AL | ||
| 40.20 10 10 | 116 x 116 x 98 | TBE 100T SS | ||
| 40.20 10 13 |
148 x 148 x 107 |
TBE 130T SS | ||
| 40.20 10 16 | 180 x 180 x 116 | TBE 160T SS |
