High-quality enclosure systems for aggressive areas according ATEX and IEC-directives
Empty enclosures for individual fittings and Ex e / Ex ia terminal enclosures
Optional version with window

Included in delivery

Empty enclosure: Enclosure with silicone seal and external earth connection.

Product Information

Technical Data
Explosion protection	II 2G Ex e IIC T6/T5/T4 Gb II 2G Ex ia IIC T6/T5/T4 Gb II 2G Ex d e ia [ia] mb IIC T6/T5/T4 Gb II 3G Ex e d mb ia [ia] nA nC [op is] IIC T6, T5, T4 Gc II 2D Ex tb IIIC T85°C/T100°C/T135°C Db IP66
Material	Stainless steel 1.25 mm or 1.5 mm; 1.4404 / 316L
Certificates	PTB 00 ATEX 1101U IECEx PTB 07.0059U EAC № TC RU C-DE.AA87.B.00971
Ingress protection	IP 66 to EN 60529
Surface	grinded, grain 240
Impact resistance	7 Joule to EN 60079-0
Temperature range	Ex B: -55°C to +135°C other seals/executions see Ex approval
Other versions on request	EMC

Product Range
Order-No.	Dimensions H x W x D (mm)	Type
34.10 10 06	100 x 100 x 61	IGExB 34010
34.15 10 06	100 x 150 x 61	IGExB 34015
34.15 15 08	150 x 150 x 81	IGExB 34020
34.20 10 06	100 x 200 x 61	IGExB 34025
34.20 20 08	200 x 200 x 81	IGExB 34030
34.20 20 12	200 x 200 x 121	IGExB 34035
34.30 15 08	150 x 300 x 81	IGExB 34040
34.30 20 08	200 x 300 x 81	IGExB 34045
34.30 20 12	200 x 300 x 121	IGExB 34050
34.30 30 12	300 x 300 x 121	IGExB 34055
34.30 30 16	300 x 300 x 161	IGExB 34060
34.38 38 16	380 x 380 x 161	IGExB 34065
34.40 15 08	150 x 400 x 81	IGExB 34070
34.40 20 12	200 x 400 x 121	IGExB 34075
34.40 30 16	300 x 400 x 161	IGExB 34080
34.50 30 16	300 x 500 x 161	IGExB 34085
34.50 40 16	400 x 500 x 161	IGExB 34090
34.60 20 12	200 x 600 x 121	IGExB 34095
34.99 99 99	Special size on request	IGExB 34100
35.10 10 06	100 x 100 x 61	IGExe 35010
35.15 10 06	100 x 150 x 61	IGExe 35015
35.15 15 08	150 x 150 x 81	IGExe 35020
35.20 10 06	100 x 200 x 61	IGExe 35025
35.20 20 08	200 x 200 x 81	IGExe 35030
35.20 20 12	200 x 200 x 121	IGExe 35035
35.30 15 08	150 x 300 x 81	IGExe 35040
35.30 20 08	200 x 300 x 81	IGExe 35045
35.30 20 12	200 x 300 x 121	IGExe 35050
35.30 30 12	300 x 300 x 121	IGExe 35055
35.30 30 16	300 x 300 x 161	IGExe 35060
35.38 38 16	380 x 380 x 161	IGExe 35065
35.40 15 08	150 x 400 x 81	IGExe 35070
35.40 20 12	200 x 400 x 121	IGExe 35075
35.40 30 16	300 x 400 x 161	IGExe 35080
35.50 30 16	300 x 500 x 161	IGExe 35085
35.50 40 16	400 x 500 x 161	IGExe 35090
35.60 20 12	200 x 600 x 121	IGExe 35095
35.99 99 99	Special size on request	IGExe 35999
36.10 10 06	100 x 100 x 61	IGExi 36010
36.15 10 06	100 x 150 x 61	IGExi 36015
36.15 15 08	150 x 150 x 81	IGExi 36020
36.20 10 06	100 x 200 x 61	IGExi 36025
36.20 20 08	200 x 200 x 81	IGExi 36030
36.20 20 12	200 x 200 x 121	IGExi 36035
36.30 15 08	150 x 300 x 81	IGExi 36040
36.30 20 08	200 x 300 x 81	IGExi 36045
36.30 20 12	200 x 300 x 121	IGExi 36050
36.30 30 12	300 x 300 x 121	IGExi 36055
36.30 30 16	300 x 300 x 161	IGExi 36060
36.38 38 16	380 x 380 x 161	IGExi 36065
36.40 15 08	150 x 400 x 81	IGExi 36070
36.40 20 12	200 x 400 x 121	IGExi 36075
36.40 30 16	300 x 400 x 161	IGExi 36080
36.50 30 16	300 x 500 x 161	IGExi 36085
36.50 40 16	400 x 500 x 161	IGExi 36090
36.60 20 12	200 x 600 x 121	IGExi 36095
36.99 99 99	Special size on request	IGExi 36999

For More Product Details
Please Scan The QR Code

Back

Ex stainless steel

发布时间：2020-11-25

阅读量：1849次

Technical Data
Explosion protection	II 2G Ex e IIC T6/T5/T4 Gb II 2G Ex ia IIC T6/T5/T4 Gb II 2G Ex d e ia [ia] mb IIC T6/T5/T4 Gb II 3G Ex e d mb ia [ia] nA nC [op is] IIC T6, T5, T4 Gc II 2D Ex tb IIIC T85°C/T100°C/T135°C Db IP66
Material	Stainless steel 1.25 mm or 1.5 mm; 1.4404 / 316L
Certificates	PTB 00 ATEX 1101U IECEx PTB 07.0059U EAC № TC RU C-DE.AA87.B.00971
Ingress protection	IP 66 to EN 60529
Surface	grinded, grain 240
Impact resistance	7 Joule to EN 60079-0
Temperature range	Ex B: -55°C to +135°C other seals/executions see Ex approval
Other versions on request	EMC
