Ex Polyglas
- Polyester Ex enclosure with hinged lid
- Easy fitting of Ex components
- Available as full assembled enclosure with terminals, cable glands and further Ex accessories or as empty enclosure, component certified
Product Information
| Technical Data | |
| Certificates |
PTB 00 ATEX 1002 IECEx PTB 08.0004 EAC № TC RU C-DE.AA87.B.00971 |
| Explosion protection |
II 2G Ex e IIC T6/T5/T4 Gb II 2G Ex ia IIC T6/T5/T4 Gb II 2G Ex d e ia [ia] mb IIC T6/T5/T4 Gb II 3G Ex e d mb ia [ia] nA nC [op is] IIC T6, T5, T4 Gc II 2D Ex tb IIIC T80°C/T95°C/T130°C Db IP66 |
| Material | glass fibre reinforced thermoset polyester, graphite added |
| Colour | RAL 9011, graphite black |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance | 7 Joule to EN 60079-0 |
| Flammability | self-extinguishing, UL 94 V-0 |
| Surface resistance | <109 Ohm to IEC 60093 |
| Toxicity |
halogen free |
| Temperature range | -20°C to +40°C (acc. T6 = 80°C max. on surface temperature) -20°C to +55°C (acc. T5 = 95°C max. on surface temperature) to -55°C with special marking on request |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 06.20 20 00 | 200 x 200 x 168 | Pog Exe 1 | ||
| 06.20 30 00 | 200 x 300 x 168 | Pog Exe 2 | ||
| 06.30 40 00 | 405 x 305 x 202 | Pog Exe 3 | ||
| 06.40 60 00 | 605 x 405 x 252 | Pog Exe 4 | ||
| 16.20 20 00 | 200 x 200 x 168 | Pog Exi 1 | ||
| 16.20 30 00 | 200 x 300 x 168 | Pog Exi 2 | ||
| 16.30 40 00 | 405 x 305 x 202 |
Pog Exi 3 |
||
| 16.40 60 00 | 605 x 405 x 252 | Pog Exi 4 | ||
| 26.20 20 00 | 200 x 200 x 168 | Pog ExB 1 | ||
| 26.20 30 00 | 200 x 300 x 168 | Pog ExB 2 | ||
| 26.30 40 00 | 405 x 305 x 202 | Pog ExB 3 | ||
| 26.40 60 00 | 605 x 405 x 252 | Pog ExB 4 |
