ROSE
Product center
EX Combibox
- Polyester GRP enclosure systems for Ex application
- Application: Ex junction boxes / Ex control stations
- Two level fitting possibility
Product Information
| Technical Data | |
| Certificates |
PTB 00 ATEX 1002 IECEx PTB 08.0004 EAC № TC RU C-DE.AA87.B.00971 |
| Explosion protection |
II 2G Ex e IIC T6/T5/T4 Gb II 2G Ex ia IIC T6/T5/T4 Gb II 2G Ex d e ia [ia] mb IIC T6/T5/T4 Gb II 3G Ex e d mb ia [ia] nA nC [op is] IIC T6, T5, T4 Gc II 2D Ex tb IIIC T80°C/T95°C/T130°C Db IP66 |
| Material | glass fibre reinforced thermoset polyester, graphite added |
| Colour | RAL 9011, graphite black |
| Ingress protection | IP 66 to EN 60529 |
| Impact resistance | 7 Joule to EN 60079-0 |
| Flammability | self-extinguishing, UL 94 V-0 |
| Surface resistance |
<109 Ohm to IEC 60093 |
| Toxicity | halogen free |
| Temperature range | -20°C to +40°C (acc. T6 = 80°C max. on surface temperature) -20°C to +55°C (acc. T5 = 95°C max. on surface temperature) -20°C to +90°C (acc. T4 = 130°C max. on surface temperature) to -55°C with special marking on request |
| Other versions on request | EMC |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 06. 01 22 15 | 177 x 177 x 145 | CB 1 Exe | ||
| 06.01 24 15 | 360 x 177 x 145 | CB 2 Exe | ||
| 06.01 44 15 | 360 x 360 x 145 | CB 3 Exe | ||
| 16.01 22 15 | 177 x 177 x 145 | CB 1 Exi | ||
| 16.01 24 15 | 360 x 177 x 145 | CB 2 Exi | ||
| 16.01 44 15 |
360 x 360 x 145 |
CB 3 Exi | ||
| 26.01 22 15 | 177 x 177 x 145 | CB 1 ExB | ||
| 26.01 24 15 | 360 x 177 x 145 | CB 2 ExB | ||
| 26.01 44 15 | 360 x 360 x 145 | CB 3 ExB |
