ROSE
Product center
olyester Ex for mining industry
- Polyester enclosures with impact resistance of 20 Joule
- Empty enclosures for individual fittings
- Silicone seal and allen lid screws
Included in delivery
- Empty enclosure: Enclosure system with silicone seal.
Junction box: Enclosure system - depending on version with silicone seal, DIN rails, internal earthing connection, terminals, continuity plate, manufacturing, cable glands.
Product Information
| Technical Data | |
| Explosion protection |
I M2 Ex e I I M1 Ex ia I |
| Material |
glass fibre reinforced thermoset polyester, graphite added |
| Certificates | IBExU06ATEX1065U |
| Colour | RAL 9011, graphite black |
| Ingress protection | IP 54 to EN 60529 |
| Impact resistance | 20 Joule to EN 60079-0 |
| Flammability | self-extinguishing, UL 94 V-0 |
| Surface resistance | <109 Ohm to IEC 60093 |
| Toxicity | halogen free |
| Temperature range | -55°C to +100°C |
| Other versions on request | EMC |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | ||
| 48.08 11 06 | 75 x 110 x 56 | ExM 48010 | ||
| 48.08 16 06 | 75 x 160 x 56 | ExM 48015 | ||
| 48.08 19 06 | 75 x 190 x 56 | ExM 48020 | ||
| 48.12 12 09 | 120 x 122 x 91 | ExM 48025 | ||
| 48.12 22 09 | 120 x 220 x 91 | ExM 48030 | ||
| 48.16 16 09 | 160 x 160 x 91 | ExM 48035 | ||
| 48.16 26 09 | 160 x 260 x 91 | ExM 48040 | ||
| 48.16 36 09 | 160 x 260 x 91 | ExM 48045 | ||
| 48.25 26 12 | 250 x 255 x 121 | ExM 48045 | ||
| 48.25 40 12 | 250 x 400 x 121 | ExM 48055 | ||
| 48.25 60 12 | 250 x 600 x 121 | ExM 48055 |
