Technical Data
Material	Profile: DIN EN 573 EN AW-AlMgSi Cast corner: DIN EN 1706 EN AC-AlSi 12 Cu 1 (Fe)
Ingress protection	IP 65 EN 60529
Seals	CR and/or PU foam
Colour	Powder coating, optional RAL 7035, light grey or, natural anodized, special colour on request
Temperature range	-30°C 至 +80°C

Product Range
Order-No.	Type
20.30 99 99	SL 3000
	P1 + P1	Mounting depth：125mm
	P1 + P2	Mounting depth：184mm
	P1 + P3	Mounting depth：225mm
	P1 + P2 + P1	Mounting depth：250mm
	P3 + P4	Mounting depth：375mm
	Profile P1	Hinged profile Mounting depth 59.5mm, outlook dimension 70mm
	Profile P2	Intermediate profile, mounting depth 119mm Outlook dimension 125mm
	Profile P3	For GT60/2 Mounting depth 159.5mm, outlook dimension 170mm
	Profile P3 direct mounting
	Profile P4	for all support arm systems Mounting depth 209.5mm, outlook dimension 220mm
	Profile P4 direct mounting
All profiles can be combined with one another. Profiles can be attached with fixed or hinged connections. If profile side is straight, the rear panel can also be designed as a door.

Accessories
	Order No.
Fixing set, M4(set=12pcs)	20.60 10 01
Fixing set, M5(set=12pcs)	20.60 10 02
Fixing set for front panel(set=12pcs)	26.60 10 03
Locking plate, powdered GT48/2 and GTK electronic	20.60 30 01
Locking plate, powdered GT 50/2 and GT 60/2	20.60 30 02
Locking plate, powdered GT 80/2	20.60 30 03
Locking plate, powdered GTK 80	20.60 30 04
Locking plate, powdered GTN II	20.60 30 05
Locking plate, anodized GT 48/2 and GTK electronic	20.60 30 11
Locking plate, anodized GT 50/2 and GT 60/2	20.60 30 12
Locking plate, anodized GT 80/2	20.60 30 13
Locking plate, anodized GTK 80	20.60 30 14
Document holder, mounted on handle	20.60 10 04
Document holder, mounted directly	20.60 10 05
Mouse holder	20.60 10 06
Coupling flange for GT 48/2 / GTK electronic	20.60 10 07
Adapter plate P1/P2 for GT80/2	20.60 10 08
Mounting set	10.03 31 01
Keyboard drawer	10.99 20 01
Rail mounting, L=80mm	54.00 00 16
Rail mounting, L=160mm	54.00 00 24
Rail mounting, L=240mm	54.00 00 32
Slim control plate 240/3	20.60 10 50
Slim control plate 335/5	20.60 10 51
Slim control plate 483/8	20.60 10 52
Positioning plate, powder coated GTN II	20.60 30 05
Positioning plate, anodized GTN II	20.60 30 15
Mouse holder	10.99 20 02
