ComTronic
- Aluminium profile compact commander in 2 widths
- Applications: Compact control equipment and display systems
- Standard integrated cooling system
- Variable length execution by profile technology
Included in delivery
- Profile enclosure body, on rear side door or screwed wall, fastening elements for front panel. Please order front panel separately
Product Information
| Technical Data | |
| Material |
Enclosure profile: DIN EN 573 EN AW-AlMgSi Lid: Aluminium DIN EN 1706 EN AC-AlSi 12 (Fe) |
| Colour | Powder coating, lid and base: RAL 7035, light grey, Multi-functional profile: RAL 9005, jet black |
| Ingress protection | IP 65 to EN 60529 |
| Temperature range |
-30°C to 65°C |
| Product Range | ||||
| Order-No. | Dimensions H x W x D (mm) | Type | weight(kg) | front panel |
| 20.80 10 10 | 442 x 365 x 118 | CT 110-350-S | 70 | 20.80 91 01 |
| 20.80 10 20 | 612 x 365 x 118 | CT 110-520-S | 85 | 20.80 91 02 |
| 20.80 10 99 | SL x 365 x 118 | CT 110-SL-S | 20.80 91 99 | |
| 20.80 11 10 | 442 x 365 x 118 | CT 110-350-S-GT | 70 | 20.80 91 01 |
| 20.80 11 20 | 612 x 365 x 118 | CT 110-520-S-GT | 85 | 20.80 91 02 |
| 20.80 11 99 | SL x 365 x 118 | CT 110-SL-S-GT | 20.80 91 99 | |
| 20.80 40 10 | 442 x 453 x 153 | CT 145-350-S | 96 | 20.80 91 03 |
| 20.80 40 20 | 612 x 453 x 153 | CT 145-520-S | 114 | 20.80 91 04 |
| 20.80 40 99 | SL x 453 x 153 | CT 145-SL-S | 20.80 91 99 | |
| 20.80 42 10 | 442 x 453 x 153 | CT 145-350-S-GT | 9.6 | 20.80 91 03 |
| 20.80 42 20 | 612 x 453 x 153 | CT 145-520-S-GT | 11.4 | 20.80 91 04 |
| 20.80 42 99 | SL x 453 x 153 | CT 145-SL-S-GT | 20.80 91 99 |
| Accessories | Order-No. | |||
| Wall holder | 20.80 90 01 | |||
| Handle set 350(L=350mm) | 20.80 90 02 | |||
| Handle set 500(L=500mm) | 20.80 90 03 | |||
| Handle set, special length | 20.80 90 99 | |||
| Cover plate, for CT110(4pcs) | 20.80 90 04 | |||
| Cover plate, for CT145(4pcs) | 20.80 90 05 | |||
| NoVoTronic-adapter P80 | 20.80 90 06 | |||
| NoVoTronic-adapter P100 | 20.80 90 07 | |||
| NoVoTronic-adapter P160 | 20.80 90 08 | |||
| Ventilator 60 for ComTronic 110(1pc) | 83.90 00 04 | |||
| Ventilator 92 for ComTronic 145(1pc) | 83.90 00 05 | |||
| Mounting set, with screws and spring nuts M5 (4pcs) | 10.03 31 01 | |||
| Fixing set, M5, Set=8pcs | 10.03 60 01 | |||
| Buttons and switches are available on request. |
