Commander 1F
- Small control enclosure in aluminium with front frame for front panels and keypads
- Robust aluminium diecast enclosure body
- Handle set (optional)
Included in delivery
- Enclosure body with two-part front frame, enclosure and fastening screws (2 or 4 pcs.). Please order front panel separately
Product Information
| Technical Data | |
| Material | DINEN 1706 EN AC-AISi 12(Fe) |
| Colour | Powder coating, Body: RAL 7038, agate grey, Front frame: RAL 7043, traffic grey B, special colour on request |
| Ingress protection | IP 65 to EN 60529 |
| Impact resistance | 7 Joule to EN 60079-0 |
| Temperature range |
PU (polyurethane) seal (std.): -40°C to +90°CCR (chloroprene) seal: -40°C to +100°CVMQ (silicone) seal (optional): -60°C to +130°C |
| Other versions on request |
Silicone lid seal |
| Product Range | |||
| Order-No. | Dimensions H x W x D (mm) | ||
| 13.07 05 00 | 260 X 160 X 109 | ||
| 13.08 05 00 | 360 X 160 X 109 | ||
| 13.10 05 00 | 230 X 200 X 129 | ||
| 13.10 05 10 | 230 X 200 X 153 | ||
| 13.12 02 00 | 230 X 330 X 129 | ||
| 13.12 05 10 | 230 X 330 X 153 | ||
| 13.13 05 00 | 230 X 330 X 199 | ||
| 13.14 05 00 | 230 X 400 X 129 | ||
| 13.15 05 00 | 230 X 400 X 243 | ||
| 13.17 05 00 | 230 X 280 X 129 | ||
| 13.20 05 00 | 310 X 400 X 129 | ||
| 13.21 05 00 | 310 X 400 X 199 | ||
| 13.25 05 00 | 310 X 400 X 158 | ||
| *Please specify handles, accessories or configuration modification if you need. | |||
