Enclosure for a range of uses with separately accessible terminal compartment
- 8 sizes, each in 6 versions
- 3 different fronts
- Metric or Pg pre-punchings
- Terminal compartment can be sealed off
- PC UL 94 V0 material is suitable for outdoor use (f1 listing acc. to to UL 746C and corresponds to requirements set R 22 acc. to DIN EN 45545-2 of hazard level HL3
- F-version front element available separately for control panel mounting
- IC 5000 version with optimal insertion grooves for circuit boards
| Characteristics | ||||
| Colour | Light grey, similar to RAL 7035; special colours on request | |||
| Protection Class | Up to IP 65/DIN EN 60529, depending on the model | |||
| Enclosure Material | ABS, PC; seal made of EPDM; UL 94 V0 types on request; for details see Technical Information | |||
Enclosure for a range of uses with separately accessibleterminal compartment
|
RCP 1000: Crystal-clear lid, hinged, withsnap lock; IP 65 |
RCP 100: With clip-on covering frame; IP40
|
RCP F: With screw-on front lid formembrane keypads; max. IP 65 |
|
The cylinder catch for retrofitting in thesnap lock protects against unauthorisedaccess.
|
A rear suspension unit ensures a concealedfit on the wall
|
All models are available on request in UL94 V0 |
|
CF: Front lid can also be used separately asan installation area. A continuous sealguarantees protection class IP 54 to theinstallation area |
IC 5000: IP 65, crystal-clear lid, hinge(hinge side freely selectable), snap lock.With a large number of horizontal andvertical plug-in slots |
|
