The modular system for this series of enclosures allows optimal integration of electronic components
- 4 widths
- The depth can be varied by combining the components (not with CC 500)
- Various fronts
- Optional rear element with separate terminal compartment (not with CC 500)
- Definable access protection
- Installation of 19" components possible
- Comprehensive range of accessories
| Characteristics | ||||
| Colour | Base elements light grey, similar to RAL 7035; front lid FD…G crystal-clear, front and rear elements graphite grey, similar to RAL 7024; special colours on request | |||
| Protection Class | Up to IP 65/DIN EN 60529, depending on the version | |||
| Enclosure Material | ABS; PC (only crystal-clear lids), seal made of EPDM; for details see Technical Information | |||
The modular system for this series of enclosures allowsoptimal integration of electronic components
|
All front, basic and rear elements in thesame basic size can be combinedindividually. |
Mounting of the enclosure components isby means of tie bars. Front and rear parts(without the base element) can bemounted directly in this way. Front andrear parts can also be mounted directly(without base element). |
Euro cards etc. can be fitted in the largemounting space.
|
|
A rear lid RD ... K with a terminalcompartment, or a rear lid with a largeterminal compartment RD...GK, offersplenty of space for various connections. |
A rear lid RD ... K with a terminalcompartment, or a rear lid with a largeterminal compartment RD...GK, offersplenty of space for various connections.
|
Crystal-clear fronts are available to providean optimal view of the electronics.
|
|
A basic element for control panel mountingacc. to DIN IEC 61554 is also available. |
Removable front panel possible as frontelement. |
|
