Characteristics
Colour	Agate grey, similar to RAL 7038; special colours on request.
Protection Class	IP 40/DIN EN 60529; ART 225 to 865: use seal set to upgrade to IP 65/DIN EN 60529
Enclosure Material	Enclosure and caps made of ABS, seal made of TPE; for details see Technical Information

The special feature of this hand-held enclosure series isits high level of flexibility

The top and bottom sides have differentdesigns and can be used alternatively asan operating and display surface.

Snap-on caps which can function as anenclosure cover are available in 6 coloursand 1 infrared-permissive version.

Up to 3 installation levels are available inthe enclosure for PCBs or mounting panels.

With sizes 555, 655 and 865, definableaccess protection can be achieved by useof the caps: tool opening, push-button, orblocking

All sizes are available with a continuousmembrane keypad area; 4 sizesadditionally with display opening includinga non-scratch window

On the cap sides a plug-in groove isprovided for front or mounting panels. Forexample, this makes it possible to useadapter connectors with protection class IP65 during field use.

The power supply to the electronics isvariable according to the size: 2-4 microbatteries, 2-6 mignon batteries and 1-2 9Vblock batteries.

Versions with fitted battery compartmentsBE 30 (9V block or 2x mignon batteries) orBE 60 (2x 9V block or 4x mignon batteries)are available on request for sizes 555, 655and 865
