1 basic size
3 heights
2 colours
3 variants (without wall brackets, with wall brackets, with wall brackets and lid fixing on top)
Design seal optional
PC material is suitable for outdoor use due to f1-listing according to UL 746C

Product Information

Characteristics
Colour	Black, similar to RAL 9005; White, similar to RAL 9003; Special colours on request
Protection Class	IP 40; with seal: IP 65 DIN EN 60529
Enclosure Material	Enclosure: PC UL 94 V0 (PC V-0 material is flame-resistant, self-extinguishing and suitable for outdoor use; f1 listing acc. to UL 746C)

The intelligent and versatile enclosure system for modernIoT sensor technology

Without wall brackets

With wall brackets (WL);Screws from the back

With wall brackets (WL DO);Screws from the front

Ingress protection IP 65 by means ofdesign seal; available in various colours.This increases the electronics mountingheight by approx. 1.7mm.

A 1.6 mm thick PCB can be clampeddirectly between the enclosure parts andoptionally hot melted and clenched via twopins.
钉固定

Recessed membrane area (0.6 mm) in thelid and base; interfaces can be fitted onfour sides.

Pressure compensation by mounting theDAE-D11 pressure compensationmembrane.For this purpose, drill (or punch) a hole inthe moulded contour from the inside andglue the membrane in position.
