This series of connector enclosures stands out thanks to its functional and modern design
- Connector enclosure series in the following version: Connector (CEE 7/7, hybrid connector type E+F), Euro plug (CEE 7/16, hybrid connector type C), safety socket
- Made of flame-resistant plastic (UL 94 V0)
- Half-shell technology ensures easy access to the electronics
- Additional types, national versions, colours and enclosure heights available on request
| Characteristics | ||||
| Colour | Traffic white, similar to RAL 9016 | |||
| Protection Class | IP 40/DIN EN 60529; IP 20/DIN EN 60529 with safety socket |
|||
| Enclosure Material | PC/ABS blend, flame-resistant, UL 94 V0 |
This series of connector enclosures stands out thanks toits functional and modern design
|
Modern, functional design |
All enclosures are made of flame-resistantplastic, IP 20 / IP 40 protected. |
Half-shell technology ensures easy accessto the electronics. |
|
Versions with and without earthing areavailable. |
Additional variants, versions for differentcountries, different colours and enclosureheights are available on request |
The lid can also be fitted turned by 180°.This ensures optimal use of the mountingspace and operating position. |
|
Mounting bosses for self-tapping screwsare provided in the base and ensure easymounting. |
