Mobile stand system
Fixed or height-adjustable version
With 2-4 rollers
Technical data | |||
Material |
Profile:DIN EN 573 EN AW-AlMgSi Base:Steel plate |
||
Paint | Powder coating | ||
Color |
Profile:Light grey RAL 7035 Base:Grey RAL 7021 |
||
Maximum load |
35kg(Moterm 1and2) 80kg(Moterm 4and5) |
Product range | ||||
Order No | Type | Height | Description | Weight(g) |
50.01 01 01 | Moterm1 | 1000mm | Fixed, 2 rollers | 22kg |
50.01 01 02 | Moterm2 | from 750mm to 1000mm | Manually adjustable, 2 rollers | 23kg |
50.01 01 04 | Moterm4 | 980mm | Fixed, 4 rollers | 28kg |
50.01 01 05 | Moterm5 | from 730mm to 1000mm | Manually adjustable, 4 rollers | 30kg |
Accessories | |||
订货号 | |||
50.01 02 02 | Adapter plate SL1000 | ||
50.01 02 03 | Adapter plate SL2000 Profile 1 | ||
50.01 02 04 | Adapter plate SL2000 Profile 2 | ||
50.01 02 05 | Adapter plate SL2000 Profile 3 | ||
50.01 02 06 | Adapter plate SL3000 Profile 1 | ||
50.01 02 07 | Adapter plate SL3000 Profile 2-4 | ||
50.01 02 08 | Adapter plate SL3000 console version | ||
50.01 02 09 | Adapter plate universal (no hole) | ||
50.01 02 10 | Adapter plate Beckhoff CP | ||
50.01 02 11 | Adapter plate ComTronic | ||
50.01 02 12 | Adapter plate SL3000 Profile 4(direct installation) | ||
50.01 02 13 | Flat panel adapter |
