Aluminium profile suspension system for heavy loads
Complete product family GTS – GTN II – GTL product family
Can be combined with GTN II suspension system / heightadjustment system GTV and control enclosures
Optional adjustment for horizontal alignment of the profile
Maximum static load 125 kg

Included in delivery

System components with fixing material and seals

Product Information

Technical Data
Material	Connecting tube: DIN EN 573 EN AW-AlMgSi Components: DIN EN 1706 EN AC-AlSi12 (Fe)
Ingress protection	IP 54 to EN 60529
Colour	Powder coating, Tube and components in RAL 7035, light grey
Free cable passage	Tube and components de Ø 70 mm

Product Range
Order-No.	Type	weight(g)
49.62 66 00	Top mounted joint	7600
49.62 70 00	Wall hinge	9500
49.62 71 00	Angle	3200
49.62 71 47	AngelGTL/GTN II	4100
49.62 72 00	Foot stand	2800
49.62 73 00	Coupling	4700
49.62 75 00	Angle coupling	5400
49.62 67 00	Intermediate joint	8400

Order-No.	Type
	Aluminum profile closed RAL 7035	Weight(g)
49.62 20 01	Standard length 0.5m	4500
49.62 20 02	Standard length 1m	9000
49.62 20 03	Standard length 2m	18000
49.62 20 04	Standard length 3m	27000
49.62 20 99	Variable length (please specify)
	Aluminum profile closed anodized
49.62 21 01	Standard length 0.5m	4500
49.62 21 02	Standard length 1m	9000
49.62 21 03	Standard length 2m	18000
49.62 21 04	Standard length 3m	27000
49.62 21 99	Variable length (please specify)
	Aluminum profile closed RAL7035 for coupling GTL
49.62 20 11	Standard length 0.5m	4500
49.62 20 12	Standard length 1m	9000
49.62 20 98	Variable length (please specify)
	Aluminum profile closed anodized for coupling GTL
49.62 21 11	Standard length 0.5m	4500
49.62 21 12	Standard length 1m	9000
49.62 21 98	Variable length (please specify)

*Note: In case of hanging version，these types are to be selected in connection with the coupling.

Belastungsdiagramm

Note: the vertical length of the profile is responsible for the load of the complete support arm system (lever arm!). Further information for this on request. The values in the load diagram are apply to an execution hanging or standing. The declarations of weight are a summary from installation weight, Commander and all components and tubes between Commander and angle.
