Technical Data
Material	Connecting tube: square ST 37 to DIN EN 10305-5 Wall thickness 5 mm and/or 8 mm Components: spheroidal graphite cast iron and/or cast aluminium Cable duct / cover: aluminium extruded profile Bearing: ball bearing Bellow: textile fabric
Ingress protection	IP 54 to EN 60529
Seals	CR and/or NBR
Colour	Powder coating, Cable duct / caps: RAL 7035, light grey, Components: RAL 7043, traffic grey B, special colour on request
Free cable passage	57cm²

Product Range
Order-No.	Type	Weight(kg)
49.90 66 01	Top mounted joint	20.0
49.90 74 01	Foot stand / wall flange	6.0
49.90 70 01	Wall hinge	17.5
49.90 67 01	Intermediate joint	14.0
49.90 71 11	Angle (FH)	9.1
49.90 71 20	Angle (AS)	3.9
49.90 75 01	Angle coupling	4.2
49.90 73 01	Coupling	3.9
49.90 00 30	Top-mounting flange Typ A	1.1
49.90 00 20	Top-mounting flange Typ B	1.1

Cable duct	Connecting tube	Connecting tube
Standard length of connecting tube	80x80x5mm	80x80x8mm
Order-No.	Order-No.	Order-No.
10.09 42 35	10.09 42 27	10.09 42 31	Standard length 0.5m
10.09 42 36	10.09 42 28	10.09 42 32	Standard length 1m
10.09 42 37	10.09 42 29	10.09 42 33	Standard length 2m
10.09 42 38	10.09 42 30	10.09 42 34	Standard length 3m
10.09 41 65*	10.09 41 59	10.09 42 68	Variable length (please specify)
