Technical Data | |
Material |
Connecting tube: DIN EN 573 EN AW-AlMgSi Components: DIN EN 1706 EN AC-AlSi12 (Fe) Cover profile: TPE |
Free cable passage |
Connecting tube: open 27 x 32 mm Connecting tube: closed 51 mm Ø System components: 51 mm Ø |
Colour |
Powder coating, Tube, components: RAL 7035, light grey, Cover profile: RAL 9005, jet black |
Ingress protection |
IP 54 to EN 60529 |
Product Range | |||||
Order-No. | Type | weight(g) | |||
49.47 66 00 | Top mounted joint | 5200 | |||
49.47 66 01 | Top mounted joint light* | 5200 | |||
49.47 66 20 | Top mounted joint (ceiling mounting) | 5200 | |||
49.47 70 00 | Wall hinge | 6100 | |||
49.47 70 01 | Wall hinge light* | 6100 | |||
49.47 70 20 | Wall hinge hanging | 6100 | |||
49.47 70 30 | Wall hinge vertical | 5900 | |||
49.47 71 00 | Angle | 1600 | |||
49.47 71 45 | Angle GTN II / GTK electronic | 1900 | |||
49.47 71 44 | Angle GTN II / GTS | 1900 | |||
49.47 71 49 | Angle GTN II / GT 48/2 | 1900 | |||
49.47 73 00 | Coupling | 2400 | |||
49.47 73 02 | Coupling Siemens-PRO | 2800 | |||
49.47 73 03 | Couplingfixed | 1300 | |||
49.47 75 00 | Angle Coupling | 2800 | |||
49.47 67 00 | Intermediate joint "Z" | 6600 | |||
49.47 67 01 | Intermediate joint "Z" light* | 6600 | |||
49.47 67 02 | Intermediate joint "S" | 6600 | |||
49.47 67 03 | Intermediate joint "S" light | 6600 | |||
49.47 75 02 | Angle coupling Siemens-PRO | 3200 | |||
49.47 00 01 | Adapter plate Siemens-PRO | 400 | |||
49.47 72 00 | Food stand fixed | 1500 | |||
49.47 71 00 81 | Angle for wall hinge | 1000 | |||
49.47 20 12 | Turnable angle | 4800 | |||
49.47 75 49 | Angle coupling on GT 48/2 | 5300 | |||
49.47 20 13 | Turnable foot stand | 3500 | |||
49.47 72 20 | Turnable foot stand with adapter plate | 3700 | |||
49.47 72 21 | Turnable foot stand | 2400 | |||
49.47 76 00 | Console flange 15° | 700 | |||
49.47 00 04 | Column | Special length | |||
49.47 80 00 | Inclining adapter | 2200 | |||
49.47 30 01 | Height adjustment unit | - | |||
49.47 30 02 | Height Adjustment unit GTN slide hanging | 13000 | |||
49.47 30 03 | Height Adjustment unit GTN slide standing | 13000 | |||
49.00 01 01 49.00 01 02 |
Basic coupling for support arm system, control unit and cabinet |
- - |
|||
49.45 69 00 | Basic coupling for support arm system, control unit and cabinet | - |
*Light: can be used for control units with low load (up to 30kg/2m) with lower swivel force.
Aluminum profile | ||||
Profile open | Weight(g) | Profile closed | Weight(g) | |
49.47 10 01 | Standard length:0.5m | 3000 | 49.47 20 01 | 2850 |
49.47 10 02 | Standard length:1m | 6000 | 49.47 20 02 | 5700 |
49.47 10 03 | Standard length:2m | 12000 | 49.47 20 03 | 11400 |
49.47 10 99 | Other length (please specify) | 49.47 20 99 | ||
Profile anodized | ||||
49.47 11 01 | Standard length:0.5m | 3000 | 49.47 21 01 | 2850 |
49.47 11 02 | Standard length:1m | 6000 | 49.47 21 02 | 5700 |
49.47 11 03 | Standard length:2m | 12000 | 49.47 21 03 | 11400 |
49.47 11 99 | Other length (please specify) | 49.47 21 99 | ||
Note: the vertical length of the profile is responsible for the load of the complete suspension system (lever arm!). Further information for this on request. The values in the above load diagram are gulty to an execution hanging or standing. The declarations of weight are a summary from installation weight, Commander and all components and tubes between Commander and angle. |
