Interzoll Modul was designed according torelevant 19‘‘ standards. For details, pleasesee “Overview of standards” in the“Technical Information“ section.

IThe Interzoll Modul frame-type plug-inunits comply with DIN IEC 60297-3-101 /IEEE 1101.1

All guide rails have sturdy snap-in fixingsto ensure a firm fit. Continuous numberingacts as a visual insertion aid.

Profile rails with BN marking: Possible usefor a railway-tested subrack and in bus andrail vehicles.

The support brackets are firmly pressed tothe side panel to cope with extrememechanical loads. All side panels arepassivated and have a conductive function.

A support profile fixed to the side panelguarantees contact with a fitted recessedfront panel or plug-in unit

During screwing, the profiles areautomatically pressed against theprotruding bosses, secured against turningand positioned exactly.

A stainless steel spring ensures securecontacting to the cover plate.
