Characteristics | ||||
Colour | Light grey, similar to RAL 7035; screw covers, brackets and feet agate grey, similar to RAL 7038; special colours on request | |||
Protection Class | Plain: IP 40/DIN EN 60529; with air vents: IP 30/DIN EN 60529 |
|||
Enclosure Material | ABS; for details see Technical Information |
ABS desktop enclosure for universal use, possibility offitting 19" components
The screw covers which are part of thestandard delivery can be plugged in forhorizontal or vertical use, as required. |
The enclosure height can be increased withoptional extension sets by 15.24 mm (3HP) or 45.72 mm (9 HP), as required |
Additional grooves for the insertion ofcircuit boards and mounting panels arelocated on the inner enclosure side (onlywith 52011). |
The boss dimensions conform to Euro cardand other formats.
|
19" internal constructions for 3 and 6 U inwidths 9, 12, 18, 21, 27, 30 and 36 HP areavailable on request. |
As an option, two or more enclosures canbe joined by means of connectionelements
|
The screw covers can be replaced with wallflanges, tip-up feet or collapsible feet (allavailable as accessories). |
The enclosure fronts can be removedseparately, which ensures efficientmounting of operating elements. |
|
