Characteristics | ||||
Colour |
Lid: light grey, similar to RAL 7035; base: agate grey, similar to RAL 7038; special colours on request |
|||
Protection Class | IP 40/DIN EN 60529 | |||
Enclosure Material | PS (polystyrene); for details see Technical Information |
This enclosure series stands out thanks to its compactdesign
Elegant-Pult is available with a continuousmembrane keypad area or with a displayscreen and membrane keypad area. |
Bosses are provided in the lid and base forfitting circuit boards or mounting panelswith self-tapping screws |
For model series EG 20.. the position of thebosses in the base is specially designed forEuro card format (100 x 160 mm). |
Wall mounting is by means of break-outkeyholes or optional wall brackets |
The enclosure can be retrofitted with aquick-release fastener |
Removable rear front surface for easyfitting of display and operating elements |
Screwing takes place from below, so noscrews are visible on top. |
|
|
